Introducing the NEW MTX 3283 from METRIX!
|
 |
Easy to use, the MTX 3283 multimeter from the MTX Mobile product family provides direct single-handed access to its functions, thanks to an electronic measurement switch. Equipped with a large multidirectional LCD screen, it has 4 100,000 point digital displays and English/French bilingual menus.
In order to optimise efficiency and safety during use, the "Ampere" and "Volt" measurement terminals allow automatic selection of the appropriate function, in AC+DC mode and default automatic range.
The MTX 3283 communicates in all environments thanks to its RS232 and optical USB ports, and its Bluetooth technology.
Large multidirectional LCD screen
Four 100,000 point displays, bargraph, graphic measurement log
200kHz specified bandwidth
0.02% basic accuracy
3 measurement terminals with automatic selection, "full current autoranging"
8-key electronic measurement switch with direct single-handed access
Functions: SPEC, AUTOP EAK, HOLD, AUTOHOLD, REL, SURV, MATH, MEM
Frequency measurements up to 2 MHz: duration, duty cycle, event metering
"Favourite Measurement" key for physical quantity (conversion or unity)
6,500 storable measurements
Optical RS232, USB and Bluetooth communication
Supply: LR6 batteries, AA NiMH rechargeable batteries, mains adapter
Safety: IEC 61010, Cat. IV 600 V , Cat. III 1000 V
EMC: NF EN 61326-1
Dimensions: 44 x 85 x 180 mm; Weight: 400 g
IP51 casing
|
|
|
|
